Custom Arc & Trapezoidal Neodymium Motor Magnets, High Performance Rare Earth Magnets for BLDC & Servo Motors 5

Custom Arc & Trapezoidal Neodymium Motor Magnets, High Performance Rare Earth Magnets for BLDC & Servo Motors

Custom NdFeB Magnets, Rare Earth Magnets for Industrial Motor Applications

If you are designing high-efficiency permanent magnet motors, BLDC motors, servo motors or generators, our custom arc and trapezoidal neodymium motor magnets are your ideal core components.

Made from high-grade sintered NdFeB rare earth material, these arc segment and trapezoidal magnets feature uniform magnetic distribution, high remanence and strong coercivity. The custom arc shape is precisely machined to fit the motor rotor and stator perfectly, minimizing magnetic flux leakage and maximizing energy conversion efficiency. Different from standard block magnets, the curved design ensures close fit with the motor housing, optimizing the air gap and magnetic circuit, which directly improves the motor’s power output and energy efficiency.

We offer full customization service for these motor magnets, including arc angle, outer/inner diameter, thickness, trapezoidal profile and special dimensions according to your drawings. Various magnetization patterns (radial, multi-pole, parallel) are available to match different motor structures. High-temperature resistant grades are provided for motors working in high-temperature environments, ensuring stable magnetic performance without demagnetization even under continuous operation.

Multiple surface coating options (nickel, zinc, epoxy, passivation) are available to meet different anti-corrosion requirements, protecting the magnets from oxidation and wear in harsh industrial conditions. The strict quality control ensures consistent batch-to-batch performance, which is critical for mass production of motor products.

These arc and trapezoidal motor magnets are widely used in electric vehicle motors, industrial automation servo motors, household appliance BLDC motors, wind power generators, aerospace equipment and precision sensors. Whether you need prototype small batches or large-scale production orders, we can provide tailored magnet solutions to perfectly match your motor design.

✅ Precision Custom Shapes: Arc segment, trapezoidal and special profiles per your drawings, tight dimensional tolerance

✅ High Magnetic Performance: High-grade NdFeB material, uniform magnetic distribution, optimized for motor efficiency

✅ High Temperature Resistance: Multiple grades available (N35~N52, SH/EH/TH series) for continuous operation in high temp environments

✅ Custom Magnetization: Radial, multi-pole and parallel magnetization patterns to match different motor designs

✅ Durable Surface Coatings: Nickel, zinc, epoxy coatings for anti-corrosion and long service life

✅ Wide Application: Ideal for BLDC motors, servo motors, generators, electric vehicles and industrial automation

WhatsApp:+86153 2281 4711

Contact us for a $500 discount >>> Go
E-mail: Lily@dghuanlin.com

Inquiry

Write a Review

High-Performance Neodymium Magnets

Upgrade your machines and products with our N52 Earth Magnets and 24v DC Motors, offering maximum strength and high performance. With 17 years of experience, we customize rare earth Neodymium magnets in various shapes, sizes, and coatings, and our products come with CE ROHS MSDS California 65 RECAH certification. Our high-quality products are suitable for use in various equipment, such as servo motors, wind turbines, speakers, electronic components, and more.

Product Display

carousel-2

carousel-5

carousel-7

Powerful N52 Magnets: Efficiency, Strength, Precision

Custom Arc & Trapezoidal Neodymium Motor Magnets, High Performance Rare Earth Magnets for BLDC & Servo Motors 11

Efficient

Our N52 Earth Magnets are designed to deliver strong and reliable power for three-phase brushless motors, 24v DC motors, and guitar pickups, ensuring consistent and efficient performance.

Excellent

The use of Neodymium magnets in our product allows for efficient and smooth operation, making it an excellent choice for conveyor belts and other industrial applications that require reliable and high-performing magnets.

High Quality

The high-quality construction and superior magnetic strength of our product make it a top choice for any project that demands powerful and durable magnets, ensuring long-lasting and reliable performance.

Reliable

Our N52 Earth Magnets are specifically designed to provide strong and reliable power for three-phase brushless motors, 24v DC motors, and guitar pickups, making them a superior choice for any application requiring high-quality magnets with reliable power.

Powerful Neodymium Magnets for Superior Performance

Our N52 Earth Magnets three-phase brushless motors, 24v DC motors, and neodymium magnets for conveyor belts are reliable and highly sought after, boasting 17 years of OEM/ODM magnetic material manufacturing experience, superior one-stop services, fast 8-12 day delivery, and 24/7 customer support. With CE, ROHS, MSDS, and California 65 RECAH certification, these products are high-quality and versatile. Our neodymium magnets are customizable in various shapes, sizes, coatings, and grades, providing the freedom to design the perfect solution for your needs, whether it's for industrial applications, guitar pickups, or other machinery.

Application Scenario

Custom Arc & Trapezoidal Neodymium Motor Magnets, High Performance Rare Earth Magnets for BLDC & Servo Motors 16

Motor Efficiency Enhancement

The N52 Earth Magnets are used in three-phase brushless motors and 24v DC motors to enhance their performance and efficiency.

Custom Arc & Trapezoidal Neodymium Motor Magnets, High Performance Rare Earth Magnets for BLDC & Servo Motors 17

Clearer Guitar Sound

They are also utilized in guitar pickups to produce clearer and more vibrant sound.

Stronger Conveyor Belts

These neodymium magnets are employed in conveyor belts to improve their strength and durability.

Enhanced Equipment Performance

The N52 Earth Magnets are used in various applications to enhance the performance and efficiency of different equipment.

Material Introduction

This product consists of N52 earth magnets, three-phase brushless motors, 24v DC motors, guitar pickups, and neodymium magnets for conveyor belts. The rare earth neodymium magnets can be customized in various shapes, sizes, coatings, and grades. Made from sintered Neodymium-Iron-Boron (NdFeB), these magnets come in various sizes and shapes, and can be coated with materials such as Nickel, Zinc, Gold, Silver, and Epoxy resin. They are available with different magnetization, and are available in different temperature grades to suit various applications such as permanent magnet servo motors, permanent magnet linear motors, and electronic components.

FAQ

How do N52 Earth Magnets benefit three-phase brushless motors?

N52 Earth Magnets provide powerful, consistent magnetic force, improving the efficiency and performance of three-phase brushless motors.

Can 24v DC motors be used in outdoor applications?

Yes, 24v DC motors can be used in outdoor applications as long as they are properly sealed and protected from the elements.

How do guitar pickups benefit from neodymium magnets?

Neodymium magnets provide strong and stable magnetic fields, which enhance the sensitivity and output of guitar pickups, resulting in clearer and more dynamic sound.

Are neodymium magnets suitable for use in conveyor belts?

Yes, neodymium magnets are ideal for conveyor belts due to their strong magnetic force, which allows for effective separation and removal of ferrous materials from the conveyed products.

Can N52 Earth Magnets be used in high-temperature environments?

Yes, N52 Earth Magnets can withstand high temperatures, making them suitable for applications where heat resistance is required.

What are the advantages of using three-phase brushless motors over traditional brushed motors?

Three-phase brushless motors have higher efficiency, longer lifespan, and lower maintenance requirements compared to traditional brushed motors, making them ideal for various industrial and commercial applications.
